18650 26650 32650 Lithium Ion Battery Assembly Equipment Battery Case Sealing

Place of Origin China
Brand Name ZHIK
Certification CE IOS
Model Number ZK-CC50P
Minimum Order Quantity 1 Set
Price 4200
Packaging Details Wooden packing
Delivery Time 14
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 15set/month
Product Details
Weight 35Kg Sealing Trip 30 Mm
High Light

18650 Lithium Ion Battery Assembly Equipment


26650 Lithium Ion Battery Assembly Equipment


Case Sealing Battery Stacking Machine

Leave a Message
Product Description
Lithium ion Cylindrical Cell Crimper Crimping Machine For 18650 26650 32650 Battery Case Sealing
Product Description

1 ZK-CC50P pneumatic sealing machine mainly used for the sample of lab battery materials’ research, which to make cylindrical battery. The research sealing of cylindrical capacitor can also be used in small batch trial production in factory. 2 Included Mould: Standard 18650 Cylindrical battery sealing mould(1 set, 2 sealing). You can also choose other Cylindrical battery sealing mould.


18650 26650 32650 Lithium Ion Battery Assembly Equipment Battery Case Sealing 0

Main features:
1 Totally operated by pneumatic. Without any electricity. Very easy to use.
2 Two steps for sealing which make better sealing.
3 Precise design of the mold ensures accurate and reliable sealing. Solid steel structure design makes a steady and safe use.
4 Good looking appearance, Simple maintenance, Small size, easy operater and accurate molding.
5 Gas supply by compressed air or Inert gas cylinder. External connection of the compressed gas make sure the balance of the
atmosphere in the glove box.
6 Precise design of the mold ensures accurate and reliable sealing. Solid steel structure design makes a steady and safe use.

Technical Parameter
ZK-CC50P Cylindrical battery sealing machine
One Year limited warranty with lifetime support
Gas source
0.6 ~ 0.8MPa argon, nitrogen cylinders, or compressed air (compressed air is not recommended in the glove box)
Exhaust gas design
specially designed exhaust ports, which can be externally connected through devices such as KF40
Gas consumption
480ml for single seal
Sealing pressure
manual control valve control, maximum pressure 1 MPA, recommended use pressure 0.7 MPa, accuracy ±0.5%
Sealing trip
30 mm
Sealing dies
Standard 18650 series package dies, it can be selected or matched with other specifications
Structural material
1.With the function of preventing the short circuit of the battery seal.
2.high strength chromium steel, the surface after environmental plating and spray treatment will never rust


Innovation in Product and Processes

Advancement in technology and materials that are taking place in the field of Li-ion cell manufacturing, will have a positive impact on production costs, reducing the cost of not only raw material but also the final battery cell. Innovation has always led to better performance and quality of the end product.

Source: Sciencedirect
  • Various mixing technologies and mixing tools are now available: intensive mixers, planetary mixers, dispersers, etc.
  • Simultaneous coating process that enables coating of the top and bottom sides of the foil at the same time using two opposite application tools.
  • Dry coating application of the active material on the carrier foil can be done in powder form without using a solvent, greatly reducing thermal activation time. Removing the solvent and drying process allows large-scale Li-ion battery production to be more economically viable.
  • The conventional dryers can be supported by infrared heating, making them more efficient
  • Lamination is a key technology for Lithium-ion battery production. The individual electrode and separator sheets are laminated onto each other in a continuous process and are then usually pressed together by a heat press, improving production line speed.
