Cylindrical Battery Automatic Spot Welding Machine Double Sided With Rotation

Place of Origin China
Brand Name ZHIK
Certification CE IOS
Model Number ZK-DAS400D
Minimum Order Quantity 1 Set
Price 9500-12000USD/Set
Packaging Details Wooden packing
Delivery Time 35 DAYS
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 15 set/month
Product Details
Equipment Power 2KW X-axis Stroke 0 -240m M
Z-axis Stroke 560mm Suitable Thickness Of Plane Welded Nickel Sheet 0.12-0.2mm Steel Nickel Plating
Suitable Thickness Of Nickel Sheet For Bump Welding 0.2 Steel Nickel Plating Plane Welding Speed 0.9-1s 3000-3200 PCS / H
Convex Spot Welding Speed 1.2-1.5s 2000-25000 PCS / H Suitable Battery Model 18650 26650 32650
High Light

Cylindrical Battery Automatic Spot Welding Machine


18650 Battery Pack Automatic Spot Welder


battery automatic spot welding machine

Leave a Message
Product Description
  • Cylindrical Battery Double Sided Automatic Spot Welding Machine With Rotation ZK-DAS400D

  • Battery double sided automatic spot welder with rotation ZK-DAS400D


一.Equipment introduction

1.The surface automatic spot welding machine supports breakpoint start and is equipped with miaki md-b4000b dual wave transistor power supply. It can weld nickel plated steel below 0.2mm. Double sided automatic welding, high efficiency. Simple programming, support any point programming and array programming, and can store 99 groups of programming files.
2.The prediction of welding needle replacement reminds that the welding head adopts water-cooled circulating heat dissipation to effectively reduce the loss of welding needle and improve the welding effect.
3.The self-contained welding current monitoring system can monitor the welding current, with false welding alarm function, and can monitor the welding in real time.



二.General layout:


Cylindrical Battery Automatic Spot Welding Machine Double Sided With Rotation 0    Cylindrical Battery Automatic Spot Welding Machine Double Sided With Rotation 1


Cylindrical Battery Automatic Spot Welding Machine Double Sided With Rotation 2

Note: overall dimension of the whole machine: (about) length: 1100mm; Width: 1000mm; Height: 1500m




三.Technical parameters:
3.1 requirements for equipment operation environment
    3.1.1 welding power supply: two-phase 110V/220V ± 10%, 50Hz ± 10%; Power < 1000 W
    3.1.2 power consumption of welding power supply: 2000W
    3.1.3 platform input voltage: 220V 50Hz platform power consumption: < 800W
    3.1.4 equipment size and length: 1500mm; Width: 900mm; Height: 1900mm
    3.1.5 equipment weight: 360kg
    3.1.6 upper and lower limit setting of welding current: support
    3.1.7 maximum speed of motor transmission: 1000 mm / S
    3.1.8 Z-axis and y-axis displacement accuracy: 0.05 mm

    3.1.9 z-axis travel 240mm, Y-axis travel 560mm

3.2 system technical indicators
    3.2.1 pressure adjustment of welding head inlet spring: 1.0-5.0kg
    3.2.2 suitable thickness of plane Welded Nickel Sheet: 0.12-0.2mm steel nickel plating
    3.2.3 suitable thickness of nickel sheet for bump welding: 0.2 steel nickel plating
    3.2.4 positive and negative current switching speed / specification: not available
    3.2.5 plane welding speed: 0.9-1s 3000-3200 PCS / h
    3.2.6 convex spot welding speed: 1.2-1.5s 2000-25000 PCS / h
    3.2.7 suitable battery model: 18650 26650 32650
